Portable Power Station Supply lifepo4 battery Camping Generator
Power Station
Quick detail of Portable Power Station
* 2016Wh high capacity.
* Can drive 90%of commonly electrical appliances.
* With bidirectional fast charging function,2 hours fully charged.
* Support 400W solar energy high-power charging.
Description:
It’s an off-grid portable battery system, also called portable
power station/solar generator/storage system/power box/AC power
bank, ect...
This unit will provide power with a range of AC/DC/USB/TYPE-C
outputs, to keep your home appliance and small electrical devices
charged & operating.
Before using this unit, please read the specifications carefully.
Specifications:
| Model | S20-2000W |
AC Output | Output Rated Voltage Input Voltage Range | 210Vac(mini) -230Vac(max) |
| Output Wave | Pure sine wave |
| Rated Power | 2000W |
| Overpower Protection | |
| Output Rated Frequency | 50Hz/60Hz ± 3Hz (Can be switched) |
| Efficiency | >85% |
| Short-circuit protection | Available |
| Over-Temperature Protection | The unit into over temperature protection mode once the temperature
reach to 80℃. |
| Operate | Press the AC button to turn on/off |
| Cell Type | LiFePO4 Battery 15A |
| Battery Features | Total capacity | mah |
| Energy capacity | 2016WH |
| Battery Pack Method | 7S6P |
Charge Performance | AC Input | Voltage Range | 210V-230V |
| Max. Charging Power | 1200W |
| Full charged Time | 2H |
Solar charging | Voltage Range | 5.7-36V |
| Max. Charging Power | 400W |
| Solar charging | Built-in MPPT algorithm |
| Car Charging | Input Voltage | 12V |
| Iuput Current 12V-30V DC MPPT |  10A |
| Discharge | USB output | 3 interfaces | 1*QC3.0 18W, 2*USB 5V2.4 |
| Performance (DC) | Cigarette lighter output | Voltage | 12V |
 Current | 8A |
| TYPE-C Output | 3 interfaces | 1*Type C, PD65W, 2*Type C, 5V2.4 |
| LED lighting | Model | On, flicker |
| Color Temperature | 4000K |
BMS Features | | Rated current | 30A |
| | |
| | |
| Protection function | - Overcharge protection;
- Over discharge protection;
- Over temperature protection;
- Over current protection;
- Over voltage Protection:
- Short circuit protection;
|
|
| Running noise | | | <10dB |
Weight and Dimension | Mainframe weight | | KG |
| Mainframe size | | (mm) |
| Package weight | UN box packaging | KG |
| | | |
| | | |
| Package size | UN box packaging | (mm) |
| H.S CODE | HS CODE | | 8507600090 |
| Qty/Container | 20 ft. | | |
| 40 ft. | | |
| Certification | | | FCC,UN38.3,UL2743, PSE,MSDS, ETL |
Why Choose US:
1. We offer one-stop power solutions, which saves design time and
cost for customer:
-- Pack design / External Case design / BMS design
2. Strict quality control system which enhances customers'
competitiveness:
-- 100% PCM test by IQC
-- 100% Capacity test by OQC
3. Delivery on time & excellent service:
-- Fast Delivery in 10 days if stock
-- 8h response & 48h solution
4. Experienced R&D team, be customer's professional power
solution consultant:
-- Comprehensive Battery Test Center (Safety and Reliable test)
-- Powerful ODM Ability to Afford Customized Design Requirement
FAQ:
Q1: Do you accept small order?
A: Yes, we accept small orders or trial orders to test
Q2: Can you accept ODM&OEM?
A: Yes, ODM and OEM are warmly accepted. We are very glad to
provide customized service for you, including packing, logo,
brand,new molds and so on.
Q3: What is delivery time if we place an order?
A: It depends order quantity. Usually, we can deliver goods within
5 -10 working days for small orders. For more quantity,let's
confirm when you place offical order.
Q4. How to proceed with an order?
A: Firstly let us know your requirements or application. Secondly,
We quote according to your require-
ments or our suggestions.Thirdly customer confirms the samples and
places a deposit for formal order.
Q5: How does your factory do regarding the quality control?
A: Quality is priority. We always attach great importance to
quality control from the very beginning to the end of the
production. Every product will be fully assembled and carefully
tested before packing and shipping.
Q6. How do you ship the goods
A: Normally, we will ship the goods by air, by sea and by express,
such as DHL, Fedex, UPS, TNT basing on the needs of different
clients.
